Tanpa Main Blades, Termasuk Tail Blades Specifications
Frame	Support frame made in xxmm carbon fiber, composite plastics and aluminum.
System transmission	Twin belt drive system. 9mm main belt, 4mm tail belt
Main blades	385mm maximum
Battery Options	LiPo from 3s to 6s. Typical setup is 1300mah to 1800mah 6s (2200mah 6s max).
Battery compartment dimensions	24mmx33mmx100mm
Suggested battery	Lipo 6s 1800mAh
Main rotor diameter	864mm (with 380mm blades)
Tail rotor diameter	181mm (with 67mm tail blades)
Total length without blades	800mm
Total length with blades	1003mm (with 380mm blades)
Main shaft diameter	6mm
Tail shaft diameter	5mm
Height	235mm
Swashplate servos	3x micro servos
Tail servo	1x micro or mini servo
Teeth pinion	21T 5mm hole included [5mm hole: 20T , 22T, 23T, 24T, 25T optional]
Main pulley teeth	120T
Tail ratio	4.27:1
Tail boom diameter	17mm
Spindle diameter	5mm

Protos380EVO V2 include new frame(MSH41233). Rigid tail blades(MSH41181-1).
